GB - 13
Zone Manager
ENGLISH
8- LOCAL UNIT OVERRIDE
If Local Unit Override is active, certain information (operating
mode, desired temperature, fanspeed, louver setting) from the
Zone Manager will be ignored by a unit that has recently been
locally controlled. The unit will control to the local settings for
at least one hour. Factory default is "OF".
To adjust when in configuration mode:
• Press the "up" or "down" button until "8-" is displayed.
• Depress the "
SET TIME/TEMP" button to change the current
selection (current selection will now blink).
• Use either the "up" or "down" button to change to "On" for active
Local Unit Override or "OF" for disabled local Unit override.
• To end configuration, either depress the "END PROGRAM" button
or do not push any buttons for 20 seconds.
9- LOCK MODE
If this option is active (Lo) after 4 minutes the installer exits
installation mode the operator will not be able to change mode
or program schedule.
If the operator press the "MODE" or "PROGRAM" button "Lo:c" will
be displayed. Default is unlocked (U
L).
To adjust when in configuration mode:
• Press the "up" or "down" button until "9-" is displayed.
• Depress the "
SET TIME/TEMP" button to change the current
selection (current selection will now blink).
• Use either the "up" or "down" button to change to "L
O" to
Lock mode and program schedule or "U
L" to allow the end
user modify these parameters.
• To end configuration, either depress the "
END PROGRAM" button
or do not push any buttons for 20 seconds.
up
down
up
down
up
down
up
down
Configuration
