Case IH AXIAL-FLOW 2588 User Manual

6 - FIELD OPERATION
156
CUTTING AND FEEDING
Controls and Adjustments
589L94
1
2
3
4
5
6
7
8
9
10
11
1. FEEDER CONVEYOR CHAIN
2. REEL
3. *AUGER TO STRIPPER
CLEARANCE
4. *AUGER FINGERS
5. *AUGER STRIPPER EXT.
6. *ECCENTRIC ADJUSTMENT FOR
TINE PITCH
7. *KNIFE SECTIONS
8. *REEL LIFT CYLINDER
9. *REEL FORE/AFT ADJUSTMENT
10. FEEDER CONVEYOR DRUM
11. FEEDER LIFT CYLINDER
*SEE HEADER OPERATOR’S
MANUAL

Case IH AXIAL-FLOW 2588 Specifications

General

Brand	Case IH
Model	AXIAL-FLOW 2588
Category	Farm Equipment
Language	English
