BALER OVERVIEW
36
Front view
1. Power take off (PTO). Drive slip clutch, and 7.
Ball hitch flywheel with shearbolt.
8. PTO drive shaft
2. Main drive gear box
9. Pick-up tines
3. Knotter monitoring flags
10. Pick-up gauge wheel
4. Bale density hydraulic circuit
11. Pick-up auger
5. Bale density pressure gauge
12. Pick-up baffle plate / roller windguard
6. Flywheel brake
13. Hydraulic / Electrical connections
