N Item Code No. Parts Name Specification
Europe
M
Europe
S
Other
countries
UK S
Drawer
Germany
Price
code
Rank
N 1 1002 9835 PCB ASSY /E268-1 E140376*6 1 EF A
N 1 1002 9841 PCB ASSY /E268-1 E140376*12 1 1 1 EE A
N 1 1002 9842 PCB ASSY /E268-1 E140376*13 1 EG A
3000 7245 FUSE 218.63 1 1 1 1 AE A
F1 3631 0330 FUSE 237001 1 AD A
IC2 2120 7393 IC/RESET S-80728AN-Z 1 1 1 1 1 AD A
N IC3 1004 2259 LSI UPD78043FGF081-3B9 1 1 1 1 1 BQ A
2006 0941 LSI BR93LC46A 1 1 1 1 1 AL A
IC4 2120 6253 IC/MOS LB1268 1 1 1 1 1 AG A
X1 2520 3445 OSCILLATOR/CRYSTAL C-002RX(M90-76) 1 1 1 1 1 AD A
X2 2801 8932 LOCK/CERAMIC CST4.19MGW 1 1 1 1 1 AC A
D1-4,8 2315 2682 DIODE 1SR35-100A-T-82 5 5 5 5 5 AA B
D5,6,9 2315 2689 DIODE 1S2075K-TD 3 3 3 3 3 AA B
N D7 1001 9404 DIODE 1S2471T-77-T 1 1 1 1 1 AA B
Q1 2250 1036 TRANSISTOR 2SD2396(K) 1 1 1 1 1 AE B
Q2 2250 1022 TRANSISTOR 2SD1803(T) 1 1 1 1 1 AF B
Q3 2250 1029 TRANSISTOR 2SD1961(S) 1 1 1 1 1 AC B
Q4 2200 9141 TRANSISTOR 2SA933(K,P,Q,R)T93 1 1 1 1 1 AA B
Q6 2250 0847 TRANSISTOR/DIGITAL DTC143ZS-TP 1 1 1 1 1 AA B
Q7 2220 2456 TRANSISTOR 2SC945(K,P,Q,R)-T 1 1 1 1 1 AA B
ZD1 2315 2675 DIODE/ZENER RD6.8EB1-T1 1 1 1 1 1 AA B
ZD2 2315 2661 DIODE/ZENER RD36EB1-T1 1 1 1 1 1 AA B
ZD3 2315 2766 DIODE/ZENER RD24EB2-T1 1 1 1 1 1 AA B
ZD4 2315 2759 DIODE/ZENER RD4.3EB2-T1 1 1 1 1 1 AA B
ZD5 2315 2654 DIODE/ZENER RD3.3EB2-T1 1 1 1 1 1 AA B
2
2408 8219 TUBE/DISPLAY 10-MT-75GC 1 1 1 1 1
BJ B
N 3
1001 8619 STAND/L DISPLAY E341001-1 1 1 1 1 1
AC C
N 4
1001 8618 STAND/R DISPLAY E341002-1 1 1 1 1 1
AC C
BZ1 3240 2089 BUZZER PKM22EPT-2001 1 1 1 1 1 AE C
C11 2807 2735 CAPACITOR/ELECTROLYTIC RE2-50V4R7M-T2 1 1 1 1 1 AA C
C14,15 2818 0446 CAPACITOR/CERAMIC RT-HE40TKYB101K-T 2 2 2 2 2 AA C
C3 2807 2658 CAPACITOR/ELECTROLYTIC RE3-25V472M 1 1 1 1 1 AL C
C4,7 2807 2315 CAPACITOR/ELECTROLYTIC RE3-10V101M-T2 2 2 2 2 2 AA C
CN1 6246 2780 CONNECTOR SUB ASSY E311971*1 1 1 1 1 1 AE C
CN2 3500 3371 CONNECTOR IL-G-2P-S3T2-E 1 1 1 1 1 AA C
CN4 3510 3465 CONNECTOR 5267-02A 1 1 1 1 1 AA C
CN6 3540 4759 CONNECTOR IMSA-9604S-21C 1 1 1 1 1 AC C
CN7 3500 1077 CONNECTOR 52011-0810 1 1 1 1 1 AC C
CN8 6246 2830 CONNECTOR SUB ASSY E412181*1 1 AP C
C1,5,17 CAPACITOR/CERAMIC RT-HE12TKYB103K-T 3 3 3 3 3 X
C10,12 CAPACITOR/CERAMIC RT-HE40TKYB221K-T 2 2 2 2 2 X
C2,16,19,28,29,30 CAPACITOR/CHIP RT-DSTC50TKYR103K 4 4 4 4 4 X
C20,23,31 CAPACITOR/CHIP ECQ-B1H103-KF 3 3 3 3 3 X
C21,22 CAPACITOR/CERAMIC RT-HE40TKCH120J-T 2 2 2 2 2 X
C8,9,13,18,24-27 CAPACITOR/CERAMIC RT-HE60TKYB222K-T 7 7 7 7 7 X
R1,15,21-23 RESISTOR CR-25-1KOHMJ-T 5 5 5 5 5 X
R10,11,18-20 RESISTOR CR-25-100KOHMJ-T 5 5 5 5 5 X
R13 RESISTOR CR-25-330KOHMJ-T 1 1 1 1 1 X
R14 RESISTOR CR-25-470KOHM-J-T 1 1 1 1 1 X
R16 RESISTOR CR-25-560OHMJ-T 1 1 1 1 1 X
R17 RESISTOR CR-25-150OHMJ-T 1 1 1 1 1 X
R2 RESISTOR CRH100-FH11J-10R 1 1 1 1 1 X
R3 RESISTOR CRH100-FH11J-1R0 1 1 1 1 1 X
R4 RESISTOR CR-25-750OHM-J-T 1 1 1 1 1 X
R5 RESISTOR CR-25-100OHMJ-T 1 1 1 1 1 X
R6 RESISTOR CR-25-24KOHM-J-T 1 1 1 1 1 X
R7 RESISTOR CR-25-75OHM-J-T 1 1 1 1 1 X
R8 RESISTOR CR-25-2.2KOHMJ-T 1 1 1 1 1 X
R9 RESISTOR CR-25-4.7KOHMJ-T 1 1 1 1 1 X
SCREW 3X12 ZMC-3... 3 3 3 3 3 X
3750 1212 SINK/HEAT OSH-1625-MP 1 1 1 1 1 AE C
3640 2331 CLIP/FUSE UF-0033 2 2 2 2 2 AA C
3000 7091 CONVERTER/DC-DC DCS-267 1 1 1 1 1 BC B
8 6221 3988 CAP/L E210964-1 4 4 4 4 4 AB C
9 6221 4025 CAP/S E311103-1 15 15 15 15 15 AA C
10 6245 7250 BUTTON/1 E311792-1 1 1 1 1 1 AB C
11 6245 7260 BUTTON/2 E311792-2 1 1 1 1 1 AB C
12 6245 7270 BUTTON/3 E311792-3 1 1 1 1 1 AB C
13 6245 7280 BUTTON/4 E311792-4 1 1 1 1 1 AB C
14 6245 7290 BUTTON/6 E311792-5 1 1 1 1 1 AB C
15 6245 7300 BUTTON/7 E311792-6 1 1 1 1 1 AB C
16 6245 7310 BUTTON/8 E311792-7 1 1 1 1 1 AB C
17 6245 7320 BUTTON/9 E311792-8 1 1 1 1 1 AB C
18 6245 7330 BUTTON/0 E311792-9 1 1 1 1 1 AB C
19 6245 7340 BUTTON/. E311792-10 1 1 1 1 1 AB C
20 6245 7350 BUTTON/00 E311792-11 1 1 1 1 1 AB C
21 6245 7360 BUTTON/5 E311116-4 1 1 1 1 1 AB C
22 6246 7768 KEYTOP/L E210963A-4 4 4 4 4 4 AD B
- 32 -
