Casio ALGEBRA FX 2.0 Plus User Manual

19990401
5-5 Drawing Two Graphs on the Same Screen
kk
kk
k Copying the Graph to the Sub-screen
Description
Dual Graph lets you split the screen into two parts. Then you can graph two different
functions in each for comparison, or draw a normal size graph on one side and its enlarged
version on the other side. This makes Dual Graph a powerful graph analysis tool.
With Dual Graph, the left side of the screen is called the “main screen,” while the right side is
called the “sub-screen.”
uu
uu
u Main Screen
The graph in the main screen is actually drawn from a function.
uu
uu
u Sub-screen
The graph on the sub-screen is produced by copying or zooming the main screen graph.
You can even make different V-Window settings for the sub-screen and main screen.
Set Up
1. From the Main Menu, enter the GRPH
•
TBL Mode.
2. On the SET UP screen, select G+G for Dual Screen.
3. Make V-Window settings for the main screen.
Press 6(RIGHT) to display the sub-graph settings screen. Pressing 6(LEFT)
returns to the main screen setting screen.
Execution
4. Store the function, and draw the graph in the main screen.
5. Perform the Dual Graph operation you want.
4(COPY) ... Duplicates the main screen graph in the sub-screen
5(SWAP) ... Swaps the main screen contents and sub-screen contents
5-5-1
Drawing Two Graphs on the Same Screen

Casio ALGEBRA FX 2.0 Plus Specifications

General

Type	Scientific
Cover	No
Form factor	Pocket
Control type	Buttons
Product color	Black
Digits	12 digits
Display type	Dot-matrix
Backlight color	Green
Backlight display	Yes
Display resolution	128 x 64 pixels
Display number of lines	8 lines
Display number of characters	21
RAM capacity	0.75 MB
ROM capacity	0.1406 MB
Storage media type	-
Battery type	CR2032, AAA
Power source	Battery
Number of batteries supported	5

Weight and Dimensions

Depth	178 mm
Width	82 mm
Height	19.5 mm
Weight	213 g
