Casio ALGEBRA FX 2.0 Plus User Manual

19990401
5-7-15
Using Tables
kk
kk
k Using Graph-Table Linking
Description
With Dual Graph, you can use the following procedure to link the graph and table screens so
the pointer on the graph screen jumps to the location of the currently selected table value.
Set Up
1. From the Main Menu, enter the GRPH
•
TBL Mode.
2. Make the required V-Window settings.
Display the SET UP screen, select the Dual Screen item, and change its setting to
“T+G”.
Execution
3. Input the function of the graph and make the required table range settings.
4. With the number table on the right side of the display, draw the graph on the left side.
4(G
•
CON) ... connect type graph
5(G
•
PLT) ... plot type graph
5. Turn on G
•
Link.
6. Now when you use c and f to move the highlighting among the cells in the table,
the pointer jumps to the corresponding point on the graph screen.
If there are multiple graphs, pressing d and e causes the pointer to jump between
them.
To turn off G
•
Link, press i or !i(QUIT).

Casio ALGEBRA FX 2.0 Plus Specifications

General

Type	Scientific
Cover	No
Form factor	Pocket
Control type	Buttons
Product color	Black
Digits	12 digits
Display type	Dot-matrix
Backlight color	Green
Backlight display	Yes
Display resolution	128 x 64 pixels
Display number of lines	8 lines
Display number of characters	21
RAM capacity	0.75 MB
ROM capacity	0.1406 MB
Storage media type	-
Battery type	CR2032, AAA
Power source	Battery
Number of batteries supported	5

Weight and Dimensions

Depth	178 mm
Width	82 mm
Height	19.5 mm
Weight	213 g
