21
Finally press the center of the cover and check to
make sure that it closes completely.
Example of incomplete closing
A large gap is present in the center of the cover
because it was not pressed into the slot properly.
This can allow moisture to get inside.
Proper and complete sealing
Closing the Serial Connector Cover
The following shows things you must do and things you need to avoid when closing the
serial connector cover.
Serial connector cover open
To Next Page
