50
Re-attaching the Jack Cover and Serial Connector Cover
The following procedures describe how to re-attach the jack and serial connector covers
to the CASSIOPEIA after they have been removed.
Re-attaching the Jack Cover
The following shows things you must do and things you need to avoid when re-
attaching the jack cover.
Jack cover removed
1 Align the raised part of the jack cover with the
groove in the case.
2 Gently pull the jack cover outwards.
3 Lower the jack cover into place.
If the raised part of the jack cover is not
completely inside of the groove, press it into place
by running your fingertip along the cover.
To Next Page
