51
Press down on one side of the jack cover and then
slide your finger to the other side so it completely
closes.
Check to make sure that the entire jack cover is
completely and correctly pressed into the case.
Re-attaching the Serial Connector Cover
The following shows things you must do and things you need to avoid when re-
attaching the serial connector cover.
Serial connector cover removed
1 Align the raised part of the serial connector
cover with the groove in the case.
2 Gently pull the serial connector cover
sideways.
To Next Page
