38
Note
• Use of a USB connection requires installation of the USB driver on your computer.
• You can also use the AC adapter/charger in place of the AC adapter in the above
configuration. See page 35 for more information.
■ To connect using a 16-pin serial cable
Important
Be sure to turn off the CASSIOPEIA and your computer before connecting the cradle.
1. Slide the cradle’s serial/USB port cover so the serial port is open.
2. Connect as illustrated below.
Note
• You can use the above configuration to connect directly to a computer’s 9-pin serial
port. If your computer has a 25-pin serial port, you will need to purchase a
commercially available connector (9-pin to 25-pin).
• You can also use the AC adapter/charger in place of the AC adapter in the above
configuration. See page 35 for more information.
■ Mounting the CASSIOPEIA Onto the Cradle
Important
Make sure that CASSIOPEIA power is turned off before you place it onto or remove it
from the cradle.
AC adapter
Cradle
Serial port
16-pin Serial cable
To Next Page
