EN-22
Connect the supplied pedal (SP-3) to the ct DAMPER/
ASSIGNABLE jack.
Back
■ To select the pedal effect
1.
Press bp FUNCTION and then use the bo dial
to display “Cntrller”.
2.
Press bp ENTER.
3.
Press bp ENTER again.
This displays the NUM indicator.
4.
Use the bo dial to select a pedal effect type.
• Available pedal effects are shown in the table below.
You can connect the optionally available 3-Pedal Unit (SP-34)
to the dk PEDAL UNIT jack on the back of the Digital Piano.
You can then use the pedals for expression that is similar to
that available on an acoustic piano.
SP-34 Pedal Functions
● Damper Pedal
Pressing the damper pedal while playing will cause the notes
you play to reverberate. The SP-34 pedal also supports half-
pedal operation, so pressing the pedal part way applies only a
partial damper effect.
● Soft Pedal
Pressing this pedal suppresses notes played on the keyboard
after the pedal was pressed, and makes them sound softer.
● Sostenuto Pedal
Only the notes of the keys that are depressed when this pedal
is pressed are sustained, even if the keyboard keys are
released, until the pedal is released.
Controlling Sounds
Using a Pedal
ct DAMPER/ASSIGNABLE jack (Standard jack (6.3mm))
SP-3
Cn t r l
ler
Peda l
Setting
Number
Parameter
(Display)
Description
1Sustain
(Sustain)
Sustains notes played while the
pedal is depressed, even if the
keyboard key is subsequently
released.
Organ and other tones that are
sustained as long as keyboard
key are depressed continue to
sound as long as the pedal is
depressed.
2 Sostenuto
(Sostenut)
Only the notes of the keys that
are depressed when the pedal is
pressed are sustained, even if
the keyboard keys are released,
until the pedal is released.
3 Soft
(Soft)
Slightly lowers and softens notes
played while the pedal is
depressed.
4Rhythm/Song
(Rhy/Song)
Pressing the pedal starts and
stops Auto Accompaniment or
song playback.
PEDAL UNIT Jack
Soft Pedal
Sostenuto Pedal
Damper Pedal
To Next Page
