Casio DT-X8 Series Quick Start Guide

㩷
If EAP-TLS radio button in Authentication field is selected, click the EAP-Properties button that
appears when selecting the EAP-TLS radio button to set the following settings.
Table 5.5
Parameters in
EAP-Properties screen
Description Default
User name Input a user name in alphanumeric (maximum 100
alphanumeric).
None
Certificate Select a client certificate installed already (maximum
100 alphanumeric).
Search button in the field will display a list of
installed client certificates. Select one by highlighting
it.
None
Domain Input in alphanumeric (maximum 100 alphanumeric) None
Validate server
certificate
Set up the requisition for server certificate.
With check mark : certificate is required.
Without check mark : certificate is not required.
Certificate is required.
3. Click WLAN tab.
Figure 5.25
Table 5.6
Field / Radio
Buttons
Description Default
On Enable power to the integrated WLAN module. Yes Adapter power
Off Disable power to the integrated WLAN module.
Enable Enable power save mode for the WLAN module. Yes Power save
Disable Disable power save mode for the WLAN module.
b Set up IEEE802.11b standard effect. Standard
b/g Set up IEEE802.11b/g standard effect. Yes
No roaming Set up “-100 dBm” for roaming starting threshold level,
a level where communication via WLAN is practically
impossible, so that roaming should not be carried out.
Default Set up “-78 dBm” for the roaming starting threshold
level.
Yes
RSSI Level for
initiating roaming
High Set up “-72 dBm” for roaming starting threshold level,
for faster (more frequent) roaming
35
