5. SETTING & CHECKING THE DIP SWITCHES
5-1. Dip switch 1 setting
No. CONTENTS STATUS STATUS
1
Reset By Dtr Signals Off Invalid On Valid
2
Reserved Off Fixed to Off
3
Protocol Off XON/XOFF On DTR/DSR
4
Baud Rate Refer to the table “a” below
5
6
Parity Refer to the table “b” below
7
8
Busy status Off Buffer full On Buffer full + OFFLINE
9
Low power consumption mode* Off Off On On
10
3 mm feed after auto cut Off Valid On Invalid
*1
Printing speed is fi xed to 150 mm/sec. max. and power consumption to approx. 8 A max.
(instantaneous value).
*2
In case of connecting by LAN, select “ON”.
Table "a" Baud rate Table "b" Parity
NO. 4800 bps 9600 bps 19200 bps 38400 bps NO. NON EVEN ODD NON
4 off off on on 6 off off on on
5 off on off on 7 off on off on
5-2. Dip switch 2 setting
No. CONTENTS STATUS STATUS
1
Data reception error Off Print “?” On Ignore
2
Bit length Off 8 bit On 7 bit
3
Reception buffer full Off *1 On *2
4
Set ID/ set IP Off Set ID On Set IP
5
Use DHCP server Off Disable On Enable
6
Set default value Off On Set default value
7
Undefi ned Off / On /
8
Undefi ned Off / On /
*1
Until the room of the reception buffer increases from 1k bytes to 2k bytes
*2
Until the non-processing data in the reception buffer decreases from 31 bytes to 21 bytes
