– 7 –
3. CIRCUITRY
3-1. POWER SUPPLY CIRCUIT
The power supply source is a DC 24V.
AC
ADAPTOR
CPU
VCC3
ROM
RAM
U1
U2
U3. 21
U13
U14
DRIVER
DRIVER
DC24V
POWER SW
U18 U19
U11
VP(+24V)
Q5
FET
VP
HVP
VCC
VCC
VCC
VCC
VP
AUTO
CUTTER
PRINTER
MOTOR
PRINTER
HEAD
BUFFER
LATCH
U7
LED DS1
VCC3
VCC3
VCC3
OTHER IC
REGULATOR REGULATOR
VCC(+5V) VCC3 (+3.3V)
