– 5 –
Precaution when assembling:
Let the connector through the hole.
Precaution when assembling:
Slide the lever of the cover to “close” and then fit the
upper cover into the printer.
4. Remove two screws.
5. Remove the upper cover while the printer cover is open.
Screws
7. Remove two screws and then the control panel.
Screws
6. Remove the screw and then the printer cover.
Screw
To Next Page
