– 15 –
V-R200 / VER.2
1-3.
About the Test Application
The test application runs.
Function Description Refer to
Red frame
Test items
TIPS: “CF Bench” is excluded from the test item.
1-5. Test Method
Set Serial Number
Checking and registering the serial number
TIPS: Carry out when the main PCB is replaced with a
new one.
1-6. Checking and
Registering the Serial
Number
Set MAC Address Not used
SDK Not used
Firmware Update
Updating the fi rmware
TIPS: This item is not used here.
TouchPanel Calibration
Touch panel calibration
TIPS: Carry out this item depending on the situation.
Auto-Run Continuous execution of the test items
Output Result Printing the test results and outputting the result fi le
Settings Launching the Android settings screen
Exit Closing the test application
Test result “OK” Test result “NG”
To interrupt the test item being tested, tap the part indicated by the red frame at the bottom of the screen.
Tap the black belt portion, to display marks.
To Next Page
