Casio V-R200 User Manual

– 67 –
V-R200 / VER.2
PARTS LIST
1: V-R200-BD 2: V-R200-BD-WE 3: V-R200-U 4: V-R200-U-WE 5: V-R200-C
12345
R RemarksN Item Code No. Parts Name Specification
Qt'y
DISPLAY-ASSY
N 15 10537626 CASE ASSY/FRONT/BK RJE504694*001 TK 1 1 A Including Touch Panel
N 15 10537627 CASE ASSY/FRONT/WE RJE504694*002 TK 1 A Including Touch Panel
N 15 10537628 CASE ASSY/FRONT/BK/DLS RJE504694*003 TK 1 A Including Touch Panel
N 15 10537629 CASE ASSY/FRONT/WE/DLS RJE504694*004 TK 1 A Including Touch Panel
16 10416295 LENS/LED RJE503847-001V02 11111C
N 17 10540727 PCB ASSY/E843-E61 RJE504581*001V01 11111B
S9
SCREW (2x6) S-BDPT-2X6Z3 33333X
N 18 10517415 LCD UNIT G104STN01.0 11111A
N 19 10544514 CUSHION/LCD RJE504664-001V01 11111A
N 20 10529356 CHASSIS/LCD RJE504536-001V01 11111X
S4
SCREW (3x8) S-BDPT-3X8Z3 55555X
21 10409528 BOX/BAT RJE503893*001V01 11111C
22 10409546 SHEET/BAT RJE503903-001V01 11111X
N 23 10540716 PCB ASSY/E843-1 RJE504603*001 TK 11111A
S2
SCREW (3x5) S-BDMA-3X5Z3 55555X
N 24 10529357 CHASSIS/HNG RJE504535-001V01 11111X
S2
SCREW (3x5) S-BDMA-3X5Z3 44444X
25 10413757 BATTERY-ASSY TK-RJE503905*001 33333B
N 26 10530397 CASE/REAR/BK RJE503837-003V04 1 1 1 X
S6B
SCREW (3x8) S-BDPT-3X8B3 5 5 5 X
N 26 10540735 CASE/REAR/WE RJE503837-004V04 1 1 X
S6
SCREW (3x8) S-BDPT-3X8NI 5 5 X
27 10409533 BLIND/DALLAS/BK RJE503838-003V01 1 1 X
27 10436469 BLIND/DALLAS/WE RJE503838-004V01 1 X
27 10409514 COVER/DALLAS/BK RJE503839-001V01 1 X
27 10476663 COVER/DALLAS/WE RJE503839-002V01 1 X
N 28 10540728 COVER/SHEET/BK RJE503841-003V02 1 1 1 C
N 28 10540729 COVER/SHEET/WE RJE503841-004V02 1 1 C
S8
10409505 SCREW (2.5x6.2) RJE503894-001V01 11111X
N 29 10540730 SPACER/SC RJE504668-001V01 22222X
30 10409516 SPEAKER 2828CP08P1-21(GP) 11111C
S9
SCREW (2x6) S-BDPT-2X6Z3 22222X
S7
SCREW (3x8) S-BD-PT-3X8Z3 22222X
N 31 10540736 COVER/BATTERY RJE503908-002V01 11111X
S3
SCREW (3x8) S-BDMA-3X8Z3 22222X
N 32 10529360 COVER/SD/BK RJE504548-001V01 1 1 1 C
N 32 10529361 COVER/SD/WE RJE504548-002V01 1 1 C
S8
SCREW (2.5x6.2) RJE503894-001V01 11111X
N 33 10540731 COVER/CONNECTOR/BK RJE503840-003V02 1 1 1 C
N 33 10540732 COVER/CONNECTOR/WE RJE503840-004V02 1 1 C
N 34 10540733 COVER/USB/BK RJE503864-003V02 1 1 1 C
N 34 10540734 COVER/USB/WE RJE503864-004V02 1 1 C
N 35 10529358 COVER/BOOT/BK RJE504544-001V01 1 1 1 C
N 35 10529359 COVER/BOOT/WE RJE504544-002V01 1 1 C
36 10322440 ASSY/DALLAS TK-RJE502827*001 1 1 B
37 10409543 SPACER/DALLAS RJE503900-001V01 1 1 X
38 10448859 FERRlTE CORE GTR-20-10-10 1 1 X
N 39 10544519 CUSHION/DLS RJE504590-001V01 1 1 X
