47
To display wired LAN information (XJ-M Series only)
1.
Press the [MENU] key to display the setup menu.
2.
Use the [T] key to select “Network Settings” and then press the [ENTER] key.
3.
Use the [T] key to select “Wired LAN info” and then press the [ENTER] key.
z This will display the Wired LAN info dialog box. The table below explains the information that
appears on the dialog box.
4.
To close the dialog box and exit the setup menu, press the [MENU] key.
Item Name Description
Projector name Blank (no name specified) under initial default settings. The name can be
changed using the procedure under “To configure Control Panel page network
settings” (page 59).
MAC Address Fixed wired LAN MAC address assigned to each projector
IP Address IP address currently assigned to the projector
DHCP Shows the current projector DHCP server function status (“Auto” or “Disable”).
To Next Page
