48
3.
Perform fast forward, fast reverse, pause, and other operations as required.
The operations described below are supported during movie file playback.
4.
To return to the file menu, press the [ESC] key.
5.
To return to the main screen, press the [FUNC] key and then the [ENTER] key.
To do this: Perform this operation:
Pause and resume movie playback Press the [ENTER] or [R] key.
A pause icon ( ) is displayed in the upper left
corner of the projection screen while movie
projection is paused.
Re-play the file from the beginning 1. Press the [FUNC] key.
2. On the menu that appears, select “Play from
Beginning” and then press the [ENTER] key.
Toggle display of the movie playback time
between show and hide
Press the [FUNC] key. On the menu that appears,
select “Time Indicator On/Off” and then press the
[ENTER] key.
Fast forward at 2X, 8X, or 32X normal speed Press the [] or [d] key.
The first press starts 2X speed fast forward, the
second press increases to 8X, and the third press
increases to 32X.
The indicator appears in the upper left corner
during 2X fast forward, during 8X fast forward,
and during 32X fast forward.
Fast reverse at 2X, 8X, or 32X normal speed Press the [] or [s] key.
The first press starts 2X speed fast reverse, the
second press increases to 8X, and the third press
increases to 32X.
The indicator appears in the upper left corner
during 2X fast reverse, during 8X fast reverse,
and during 32X fast reverse.
Return from fast forward or fast reverse to
normal playback
Press the [ENTER] key or [R] key twice. Pressing
either of these keys only once will pause playback.
Press once more to start normal playback.
Jump to the final movie frame Press the [FUNC] key. On the menu that appears,
select “Go to End” and then press the [ENTER] key.
Stop movie file playback and return to the file
menu
Press the [ESC] key.
Total movie play time
Elapsed movie play time

Table of Contents

Other manuals for Casio XJ-V10X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio XJ-V10X and is the answer not in the manual?

Casio XJ-V10X Specifications

General IconGeneral
Number of colors1.073 billion colors
Native aspect ratio4:3
Projection distance1.95 - 2.87 m
Projection technologyDLP
Contrast ratio (typical)20000:1
Screen size compatibility30 - 300 \
Projection distance (tele)3.33 - 4.85 m
Projector native resolutionXGA (1024x768)
Keystone correction, vertical+ 30/ ± 30 °
FocusManual
Offset50 %
Digital zoom2 x
Optical zoom1.5 x
Zoom capabilityYes
Focal length range2.31 - 2.73 mm
DVI portNo
Audio (L/R) in0
Serial interface typeRS-232C
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum digital resolution1920 x 1080 pixels
Operating temperature (T-T)5 - 35 °C
PlacementDesktop, Ceiling
Product typeStandard throw projector
Product colorWhite
Power source-
Power consumption (standby)180 W
Service life of light source10000 h
Service life of light source (economic mode)6000 h
Analog signal format systemNTSC, PAL, PAL 60, PAL M, PAL N, SECAM
Weight and Dimensions IconWeight and Dimensions
Width299 mm
Height97 mm
Weight3500 g
