Casio XJ-V10X User Manual

64
Supported Operations during Projection over a USB connection
The operations described in the table below are supported on the CASIO USB Display window during
projection.
To do this: Perform this operation:
Start (resume) computer screen projection
Click .
Freeze computer screen projection
Click .
Stop computer screen projection and project the USB
display standby screen
Click .
Start audio output from a computer*
1
Click . On the menu that appears, select “Audio
Out” so there is a check mark next to it.
Mute audio output from a computer*
1
Click . On the menu that appears, select “Audio
Out” to remove the check mark next to it.
Output the computer’s main screen on the projection
screen
Click . On the menu that appears, select “Select the
Projection Screen” 3 “Main Screen”.
Output the computer’s extended screen on the
projection screen*
1
*
2
Click . On the menu that appears, select “Select the
Projection Screen” 3 “Extended Screen”.
Minimize the CASIO USB Display window Click .
Exit the CASIO USB Display window (1) Click . Or you could click and then click
“Exit” on the menu that appears.
(2) On the confirmation dialog box that appears, click
the [OK] button.
 This stops computer screen projection and
projects the “USB Display” standby screen.
Display CASIO USB Display version information Click . On the menu that appears, select “About”.
*1 With Mac, installation of driver software is required to enable these functions. See “Add-on Driver
Software for Mac OS” (page 63).
*2 This operation is disabled under Mac OS 10.6. With Windows XP and Windows Vista, installation of
driver software is required to enable these functions. See “Add-on Driver Software for Windows”
(page 62).

Casio XJ-V10X Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	4:3
Projection distance	1.95 - 2.87 m
Projection technology	DLP
Contrast ratio (typical)	20000:1
Screen size compatibility	30 - 300 \
Projection distance (tele)	3.33 - 4.85 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	+ 30/ ± 30 °
Focus	Manual
Offset	50 %
Digital zoom	2 x
Optical zoom	1.5 x
Zoom capability	Yes
Focal length range	2.31 - 2.73 mm
DVI port	No
Audio (L/R) in	0
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Maximum digital resolution	1920 x 1080 pixels
Operating temperature (T-T)	5 - 35 °C
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	-
Power consumption (standby)	180 W
Service life of light source	10000 h
Service life of light source (economic mode)	6000 h
Analog signal format system	NTSC, PAL, PAL 60, PAL M, PAL N, SECAM

Weight and Dimensions

Width	299 mm
Height	97 mm
Weight	3500 g
