Caterham Seven - Figure 3: Dashboard Layout for Seven 485; Superlight R400 (Reverse for RHD)

11
NOTE: For full windscreen option the wiring connection to dashboard buttons for heated screen, wipers etc are
already connected.
Controls
1. Dipped / Side Lights
2. Main Beam switch
3. Left indicator switch
4. Speedometer
5. Rev Counter
6. Sport Mode switch
7. Wiper switch
8. Washer jet switch
9. Hazard switch
10. Right indicator switch
11. Horn switch
12. Start switch
13. Fog light switch
14. Fan control switch
15. Heated screen switch
16. Handbrake indicator
17. Oil pressure gauge
18. Temperature Gauge
19. Fuel Gauge
Figure 3: Dashboard layout for Seven 485/ Superlight R400 (Reverse for RHD)
