Table 9: Torque Figures
Location
Washers
Torque
Nm
Front lower wishbone front
Spring and plain
82
Front lower wishbone rear
Plain spacers
82
Front upper wishbone front
N/A
34
Front upper wishbone rear
N/A
34
Front spring damper top
Spring and plain
20
Front spring damper bottom
Loctite
20
Upright top ball joint
N/A
55
Upright bottom fixing
Spacer (widetrack only)
55
Front anti-roll bar clamps
N/A
20
Steering rack clamps
Plain under bolt head
11
Steering column universal joint
N/A
20
Steering column clamp plate
Spring and plain under bolt
head
14
Track rod end to upright
N/A
34
Upper differential mounting
Plain under bolt head and
nut
55
Lower differential mounting
Plain under bolt head
55
Propshaft
N/A
48
Rear spring damper top
N/A
55
Rear spring damper bottom
Spring and plain
55
Watts link locknut
N/A
20
Bellcrank to link
N/A
14
Watts link rear mount
34
Watts link front mount
34
Bellcrank to De Dion
34
Radius arm
34
'A' frame
N/A
82
Hub nuts
Thrust
271
Hub mountings
N/A
48
Brake calliper
Plain and spring
48
Rear anti-roll bar clamp
Plain under bolt head and
spring under nut
7
De Dion ears
Plain and spring
48
