Caterham Seven - Service schedules - K6 A Suzuki Engine Variants

49
Table 10: Torque Figures continued
Location
Washers
Torque
Nm
Gearbox to bell-housing
Spring under bolt head
48
Gearbox mount
Spring under bolt head
61
Engine to bell-housing
Spring under bolt head
48
Bell-housing to sump
N/A
20
Starter motor
Spring under bolt head
34
LH engine mounting bracket
Spring under bolt head
34
RH engine mounting bracket
Spring under bolt head
34
Engine mounting rubbers
Plain between chassis and
nut
20
Engine mounting to rubbers
Spring under bolt head
34
Gearbox mount to chassis
Plain between chassis and
nut
20
Exhaust manifold
N/A
34
Expansion tank bracket
Plain under bolt head and
nut
10
Gearlever to tail-housing
N/A
20
Brake banjo bolt
Copper washer each side of
banjo
10
Brake unions
N/A
10
Seat belt / harness bolts
48
All roll over bar fixings
20
Petty bar
48
Wheel nuts (2 part nut and
tapered washer)
Tapered
75
