Catrike MAX - Page 28

REV 12.18.24 Pg.27 MAX
EKIT BATTERY CLAMP ASSEMBLY
BATTERY MOUNT CLAMP WELDED
# BC1419
BATTERY MOUNT OUTER CLAMP
# BC1420
BATTERY MOUNT CLAMP SHIM
# BC1423
WRAP AROUND MAINFRAME TUBE
M6 SMALL OD WASHER (2x)
M6x25 SHCS (2x)
LIGHTLY GREASE THREADS
DO NOT TIGHTEN
BOLTS ALL THE
WAY YET
