Cayin CS-6 PH - Specifications

4
Specifications
◆ To reduce the risk of electric shock, do not remove the cover.
◆ No user serviceable parts inside. Refer servicing to qualified
service personnel.
◆ To reduce the risk of fire or electronic shock, do not expose
the unit to rain or moisture.
The lightning flash with arrowhead symbol is intended to alert user to the presence of uninsulated
“dangerous voltage” within the product's enclosure that may be of a risk shock to persons.
The exclamation point is intended to alert user to the presence of important operation and maintenance
(servicing) instructions accompanying the appliance.
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
Item
Specification
MM
MC
【 】Output Voltage
200mV (20V MAX)
200mV (20V MAX)
【 】Plusgaining
40dB
57dB/61dB/65dB
【 】Frequency Response
+/-0.2dB
+/-0.2dB
【 】THD
0.05% (1 Hz)K
0.1% (1KHz)
【 】Input Sensitivity
2.5mV (200mV，1KHz)
0.12~0.25mV (200mV，1KHz)
【 】Input Impedance
47KΩ
47Ω/100Ω/200Ω/470Ω/1000Ω
【Cap】
47pF/100pF
56pF
【 】S/N Ratio
85dB (A-weighted)
70dB (A-weighted)
【Channel separation】
90dB
80dB
【 】Output Impedance
200 600Ω XLR (Balance)Ω RCA (Unbalance) 、
【 】Input Terminals
RCA x2
【 】Ouput Terminals
RCA x1 XLR x1、
【 】Tube
Electro-Harmonix
Electro-Harmonix
6922EH/ECC88 x 2、 JJ 12AX7/ECC83 x 2、
12AT7EH/ECC81 x 2、 RCA 22DE4 x 2
【 】WDH
360mm x 309.5mm x 177mm
【 】Net Weight
11.5KG
【Fuse】
～220V-240V ～100V-120V：T500mAL250V； ：T1AL250V
【 】Max Power Consumption
62W
【 】Working Condition
Temperature °C °C Moisture 0 ~40 20%~80%
【 】Storage Condition
Temperature °C °C Moisture -20 ~70 20%~90%
