Cayin CS-6 PH - Rear Panel Connections; Rear Panel Ground Terminal; Rear Panel MC Input Terminal; Rear Panel MM Input Terminal

8
Rear Panel
T500mAL25 V0
62
RCA
XLR
MC MM
GND
OUTPUT
INPUT
ZHUHAI SPARK ELECTRONIC EQUIPMENT CO., LTD.
RISK OF ELECTRIC SHOCK
CAUTION
DO NOT OPEN
-CS 6PH
VACUUM TUBE PHONO PREAMPLIFIER
①
②
③.MM input
.
④.RCA output：
.
⑤.XLR output：
Connect to balance XLR input of power amplifier.
⑥.RCA/XLR switch
Switch between RCA output and XLR output.
⑦.Power Socket with Main Fuse
Main fuse is located just below the power socket.
.
Connect to the GND terminals of turntable.
. ：
Connect to MC input source.
：
Connect to MM input source
Connect to unbalance RCA input of power amplifier
Ground
MC input
：
：
：
2 5
6
7
41 3
