CBE PC-540HY - PC-540 HY Control Panel Functions; On;Off and Standby Operation; Battery Voltage and Current Control; Water Tank Level Monitoring

25
1)
2)
3)
5)
6)
9)
On/offgeneralswitch(toturnonpressfor2seconds):
ashortpressureturnsbetween“ON”and“STANDBY”;
atwosecpressureturnscompletelyoffthesystem.
-”ON”mode:completesystem’sanduser’soperation(LEDindicatestheoperationofevery
user).
-“STANDBY”mode:heating,antiice,gasvalveandgasdetectoroperation.
Inthismodetheuser’sbuttonsaredisabledexceptingthoserelatedtotheheatingsystem,
whichremaininthe“ON”mode.
User’sLEDaredisabledandsubstitutedbyasignappearingontheLCD(allalarmsare
disabled,exceptinggasdetectorandgasreserve.
Buttonforcontrolofcarandleisurebatteriesvoltage(inVolt)andloadandrechargecurrent(in
Ampere)fortheleisurebattery(seealso“AMPMETER”function).
Buttonforcontrolofdrink,recoveryandwastewatertank(in“%”)andfordrinkwaterrefillingfunction
operation(see“DRINKFILLING”function).
“PROG”buttonforsystem’sprogramming(seeSETTING).
Buttonsforprogrammableparameters’ setting(seeSETTING).
Buttontoswitchthepumponandoff(see“PUMP BLK”function).
Controlbuttonforengineheatingexchanger.
Buttontoswitchontheanti-iceresistor“Eis-ex”.
Gasvalvecontrolbutton;thecommutationstart/lowconsumptioniscontrolledautomaticallybythe
microprocessor.Gasvalveisautomaticallyclosedbygasleakagealarm.
Volumetricalalarmon/offbutton;thisfunctionisoperatingalsowhenthecontrolpanelisswitchedoff.
Gasdetectoron/offbutton; .
Duringatestfunction(batteriesref.02andtanksref.03)itispossibletomaintainthe
visualisationforoneminutebypressingthe“PROG”button(ref.)
- Tocancelanalarmsignalling,pressoneofthebuttons ref.05.
4)
7)
8)
10)
11) gasvalvemustbeoperating
NB:-
56
“PC-540HY ” CONTROLPANEL
1
2
3
4 5
6 7 8
9 10 11
Flair
PC-540HY
Motor
ENGLISH
