“A2018”BATTERYCHARGER
Theswitchingbatterycharger,series A200,isabletochargethegelbattery(B2leisurebattery)orthe
lead-acidbattery(carbattery)automatically.
Thehighfrequencyswitchingtechnologyallowstogetefficiencywithreducedsizesandweights.
Thechargeoccursinthreedifferentphases:
- maxcurrent,electronicallylimitedupto14,4V(25°C).
- at14,4V(25°C)constantfor:1h(Pb-Acid)or6h20'(Pb-Gel)
- at13,8V(25°C)constantuptoamaininsertion.
Maxrecharge:
Endcharge:
Maintenance:
1)
2)
3)
4)
5)
6)
FusesignalLED:itswitchesonwhenthefuseisdamaged,onlyifaloadisconnectedtothebattery.
Connectortothetemperaturesensor(OPTIONAL).
Selectorfortemperaturesensor.
Selectorforbatterytype:“Pb lead-acidbattery,“Gel lead-GEL battery.
RedLEDtosignaltherecharge(14,4V),greenLEDtosignalthemaintenancephase(13,8V).
Securityon/offswitch.
NB: whenthetemperaturesensorisnotconnectedsetto“O”otherwisethebatterychargerwon’t
work.
” ”
FUNCTIONS
Retro
Chargetemp.controlled
Max.chargingcurrent18A
Outputpower300VA
Input180/250V50/60Hz
by
230V
Readtheinstructionsbeforeuse MadeinItaly
Installinacoolandventilatedplace
U
I
IUoUcharacteristic
t40/Ea
C°
Gel
Pb
ELECTRONICBATTERY CHARGER
Mod. A 2018
6h
1h
C°
I
O
14,4V
13,8V
ALARM
FUSE
1 2 3 4 5 6
