CBE PC-540HY - Control Panel Functions and Displays; Cockpit Panel Button Functions; Cockpit Panel Alarm Display

CONTROLPANELS
42
1)
2)
3)
4)
5)
6)
7)
8)
9)
Cabin light button
Fog-headlights button.
Fog-headlights pilot light (green).
Rear-view mirror heating system button.
Rear-view mirror heating system pilot light (green)
Step retract button
Acoustic alarm and flashing red pilot light, when step is out and engine is on
Left shutter button
Right shutter button
Symbolsarelightedon(orange)whenheadlightsareon.
RL
1 2 4
53
6
7
8 9
COCKPITPANELFORDUCATO244
COCKPITPANEL
Thepaneldisplaystheexternaltemperatureandthealarms:
-Presenceofgasintheroom“GAS ALARM”.
-230Vpluginserted“230VCONNECTED!”.
-Stepout“STEP OUT”.
-Cabinseatsinwrongpositionfordriving“SEATS ALARM”.
-LockerLEFT openwithengineon“L/HLKROPEN”(OPTIONAL)
-LockerRIGHT and/orlockerbackopenwithengineon“R/H-BKLKROPEN”(OPTIONAL)
-Van'sdoorand/ordriver'scabopenwithengineon“DOOROPEN”(OPTIONAL)
A visualalarmwithfixredlight(ref.2)showsthepossibilityoficyroadwhentheexternaltemperatureis
lowerthan3°C.
Displayisactivatedonlywhenengineison.
Whenanalarmappears,thepanelbeepsthreetimes.Bypushingthebuttonref.1itispossibletocancel
thevisualizedalarm.
1
2
