STARTALARM
CARBATTERYALARM(B1)
LEISUREBATTERYALARM(B2)
MINIMUMVOLTAGECONTROL(BATTERYPROTECTION)
TANKS
Alarmisactivatedalsowithpaneloffwhen,whileconnectedwiththe230Vnet,startkeyisoperated.
Alarmsignalsacousticallyandvisuallywiththemessage“230VCONNECTION”andthenblinkingof
symbolsref.02and04.
Whencarbatteryvoltageislowerthan12V,the“MOT.B.DISCHARGE”alarmisactivatedautomatically
andsymbolsref.06and07startblinking.
Whenleisurebatteryvoltageislowerthan11V,“LEIS.B.RESERVE”isautomaticallyactivatedtogether
withsymbolsref.05and07blinking.
Whenleisurebatteryvoltageislowerthan10,5V,“LEIS.B.DISCHARGE”alarmisactivated.
Theelectronicbatteryprotectiondevicecutsoffthe12Vusersin subsequentstepswhenleisure
batteryisdischarging.
- Thefirststepisat10Vanddisables:rightandleftneonlights,pump,lights,radio,awninglight,
controlledinternallight,engineheating,auxiliaryexitand12Vsockets.
- Thealarmissignalledacoustically(2shortbeeps)andvisuallywiththemessage“BATTERY
SAVER”andbytheblinkingofsymbolref.08.
- Thesecondstepisat9,8Vanddisables:stove,“Eis-ex”anti-iceresistor,gasvalve,gasdetector
andcontrolpanel.
- Thethirdstepisat9,5Vanddisables:alimentationofthegaspiezoelectricdeviceandboiler’s
anti-icevalve.
Whenvoltageisbiggerthan10,5V,itispossibletoreactivateallusersforoneminutebypressingthe
on/offbutton(ref.01oncontrolpanel)orseparatelybypressingtherelatedcontrolbutton.
Usersareautomaticallyreactivatedwhenvoltageisbiggerthan12,5V.
Thisdevicedoesn’tcontrolthefunctions:fridge,stepandtheauxiliaryexitRES.
Drinkwatertankwithelectronicprobe:visualizationin“%”withnumericalindication,andgraphically
withrepresentedtankfilling.
Recoverywatertank:electronicprobe:visualizationin“%”withnumericalindication,andgraphically
withrepresentedtankfilling.
Sewagewatertank:threelevelprobe:visualizationin“%”withnumericalindication,andgraphical
withrepresentedtankfilling.
a)
b)
c)
CARBATTERYRECHARGE(B1)
LEISUREBATTERYRECHARGE(B2)
Withbatterychargerorsolarpanel:anelectronicdevicecontrolledbythemicroprocessorallowsthe
recharge(max4A)ofcarbattery(B1)onlyifithasavoltagelowerthan12,5Vandifthevoltageof
leisurebatteryisbiggerthan13.6V.
Priorityisgiventoleisurebattery(B2)charge.
Functionisdisplayedbythesymbolref.03oncontrolpanel.
Withsolarpanelthedeviceisoperatedonlywhencontrolpanelison,when230Vnetisconnectedthe
deviceisautomaticallyoperated.
throughenginealternator:throughseparativerelayswhenengineison. Theignitionelectronically
controlstherelays:parallel,fridge,awninglight,etc.
trough230Vnet:padsystemthroughbatterycharger(seeBATTERY CHARGER)
troughsolarpanel:throughsolarchargeregulator.
a)
b)
c)
FUNCTIONS
