CBE PC-540HY - Page 36

13)
14)
15)
16)
17)
18)
19)
20)
21)
22)
23)
24)
5A fuseforswitchedlivelightpowersupply,dependsongeneralswitch.
7,5A fuseforengine’sheatingpowersupply,whichworksin“ON”modeonly.
15A fusefor“RES”auxiliaryexitpowersupply,whichisdirectlyconnectedtoleisurebatteryi(B2).
20A fuseforpowersupplyoflightgroup“3”,whichworksin“ON”modeonly.
15A fuseforauxiliaryexit“RH”powersupply,whichworksin“ON”modeonly.
20A fusefor12Vsocketspowersupply,whichworksin“ON”modeonly.
10A fuseforalarmsystempowersupply,dependsonalarmswitchandcanbeactivated/deactivated
inmode“ON”only.
10A fusefor“TrumaC”heatingpowersupply,whichworksbothin“ON”modeandinheatingmode.
3A fuseforpowersupplyofgaspiezoelectricfiringdevice(fridge,kitchen,etc.)andboiler’santi-ice
gasvalve,whichisdirectlyconnectedtotheleisurebattery(B2),alwayson,seeanti-icevalve
function.
5A fuseforeis-exandgasvalvepowersupply,whichworkbothin“ON”modeandinheatingmode.
Controlcard(ASSEMBLECAREFULLY)
AESfridgeconnection;Itisabridge,whichexcludesthe3wayfunctionfridgeandisusedtoconnect
the AESfridgedirectlytotheB2.
36
CONNECTIONS
27 28 29 30 3231
PANEL
Tobeconnectedtocontrolpanel
PC-540HY.
BLACK
26
12VINPUT
25
TobeconnectedtoDS-340HY
(ref.29)
BLACK
WHITE
BLACK
WHITEWHITE WHITE
DS-340HYCONNECTION
123456
789101112
18 17 16 15 14 13
4
8
12
3
7
11
1
5
9
2
6
10
1 2 VI N P U T
SUPPLEMENTARYBOARD
Tobeconnectedtothe
supplementaryboardDS-340HY.
BLACK
33
