6. Auto Clear Setup
After displaying , a time of an auto clearance is displayed.
Time to carry out the zero clearance of the display is set up
by UP or DOWN. (A setup every 0.5 seconds is possible in 0.1 - 3.0)
It increases by UP . It decreases by DOWN.
Setup-time selection
0.0C-0.1C-0.5C-1.0C-1.5C-2.0C-2.5C-3.0C-0.0C
If it sets up by 0.0C, it will become the zero clearance
in manual operation. * When set up except 0.0C,
a zero clearance is not carried out even if it pushes a Clear key.
If a setup is completed, the PRG key will be pressed again.
7. Setup of a screw bundle number
After displaying ,number of counts is displayed.
A screw bundle number is set up by UP or DOWN.
(1-99 Only the direction of the right (CW))
If a setup is completed, the PRG key will be pressed again.
8. Setup of interval time
After displaying time of an interval will be displayed,
set up by UP or DOWN.
(A setup is possible in 2.0 - 24 seconds (every 2 seconds))
If a setup is completed, the PRG key will be pressed again.
9. Setup of Buzzer
After displaying , an ON-OFF-FF setup of a buzzer
is displayed. How to sound a buzzer is set up by UP and DOWN.
（ ：Sound altogether ：Don't sound
except exaggerated torque. ：Only NG sounds.）
If a setup is completed, the PRG key will be pressed again.
10. Setup of Unit
After displaying It becomes a torque display.
If the UP key is pressed, a measurement unit will change.
If a measurement unit changes, a buzzer will become.
If a setup is completed, the PRG key will be pressed again.
11. End of Setup
It is displayed and is a setting end. Green LED disappears.
(The inside of setting mode has turned on Green LED )
* When ending a setup on the way, press the CLEAR key.
When auto clear time is set as 1
Push UP twice
Push PRG/SET
When setting up for sounding a buzzer
Push PRG/SET
When a count is set as 10
Push UP 10 times
When interval time is set as 10 seconds
Push UP 10 times
