Installation and control elements
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
10. Close the protective lid, the blade guard ap and
tighten the clamping screws (g. 4.17 and 4.20).
11. Check the running smoothness and blade xing by
a short run of the freely rotating saw blade (refer to
section 4.4).
If necessary, re-tighten the cutting shaft screw.
DANGER!
Danger due to insufcient saw blade
xing and wobbling diamond saw blade!
A saw blade with insufcient core tension is noticeable
by an untrue and wobbling run.
4.5.4 Changing the cutting side
The joint cutter CF-2116 can be used for right or left
side cutting.
For converting the CF-2116 D from right to left side cut-
ting (and vice-versa) proceed as follows:
1. Dismount the diamond saw blade (refer to section
4.5.3).
Put aside the blade receiving ange, the clamping
ange and the cutting shaft screw (g. 4.19).
2. Close the blade guard (ap) and dismount the blade
guard’s protective lid by loosening and removing
the 2 clamping screws (with washers) (g. 4.17 and
4.18).
3. Dismount the splash guard by loosening and remov-
ing the xing screw (with washer) (g. 4.24).
4. Disconnect the cooling water hose from the water
pump (pumped water) or from the water tank (water
supplied under pressure – as per section 4.7 and g.
4.27).
5. Loosen the nut (with washer) at the fore interior of
the blade guard (g. 4.25) and loosen and remove
the two xing screws (with washers) rear at the blade
guard (g. 4.26).
6. Lift the blade guard off the cutting shaft (g. 4.27).
CF-2116 D standard, mounted splash guard Fig. 4.24
Nut at inner side of blade guard Fig. 4.25
