Maintenance and care
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
Electro-hydraulic compact unit in CF-2116 D (right) Fig. 6.13
control/ller plug (red)
In cold condition the oil lling level in the collecting tank
(joint cutter standing horizontally with lowered cutting
shaft) has to reach the edge of the control/ller plug. If
necessary, ll up oil.
Keep the compact hydraulic unit clean to prevent over-
heating as this might damage the electric motor.
3. Clean the area around the control/ller plug on the
electro-hydraulic compact unit (laterally, approx. in
the center g. 6.11 and 6.13).
4. Open the red plastic plug (control/ller plug) and
if necessary, ll up the corresponding quantity of
hydraulic uid (table 6.7) by means of a funnel or
something similar.
Pay attention to highest level of cleanliness of
the hydraulic uid! Dirt or water must not get
into the hydraulic circuit.
5. Close the control/ller plug at the compact hydraulic
unit (g. 6.11 and 6.13).
6. Raise and lower the cutting shaft (sect. 4.3.1 and
4.5.3).
7. Lower the cutting shaft completely and stop the joint
cutter’s motor.
8. Check the hydraulic oil level of the compact hydraulic
unit (as previously described),
9. Repeat as described in 4. to 8. until the compact
hydraulic unit is sufciently lled!
10. Screw the control/ller plug (red cap) rmly.
Overlled hydraulic uid will be pressed out
through the control/ller plug (ventilation
hole)!
Therefore the oil collecting tank must not be lled up to
the brim when the cutting shaft is raised!
11. Collect the leaking hydraulic uid.
Collect and discharge the used and leaked
hydraulic uid environment-friendly, according
to the local laws.
Provide information from the competent authority!
12. Put the water tank back on the water tank console.
6.6.8 Checking/greasing the
feed gear drive
DANGER!
Maintenance works must only be carried
out when the joint cutter has been shut
down.
The feed gear drive is part of the feed drive and mount-
ed in the gear housing between the hydrostatic gear
and the chain drive for the drive wheels (g. 6.14 and
6.16).
water tank console feed gear drive
CF-2116 D rear side Fig. 6.14
Check and grease the CF-2116 D’s feed gear drive as
per maintenance table 6.5. Proceed as follows:
1. Remove the water tank.
2. Dismount the water tank console from the CF-2116
D by loosening and removing the 4 screws and nuts
(g. 6.13 and 6.14).
