47
Maintenance and care
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
CF-2116 D superstructure box right; view on the water tank
console (water tank removed) Fig. 6.15
2 of 4 screws/nuts
3. If necessary, clean the feed gear drive by removing
adhering dust and old grease (g. 6.16).
4. Check the pinion and the gearwheel on even wear
(clearance), quantity and completeness of teeth (g.
6.16).
5. Grease the feed gear drive by applying a thin lm of
multi-purpose grease with a brush on the teeth (g.
6.16).
Excessive greasing will increase wear due to
adhering dust and slurry.
CF-2116 D water tank console dismounted, view in the gear
housing Fig. 6.16
hydrostatic gear pinion gear wheel
chain drive for drive wheels
6. Mount the water tank console with the four screws
and nuts (gs. 6.14 and 6.15) and re-tighten all loos-
ened screws.
7. Place the water tank back on the CF-2116 D water
tank console.
6.6.9 Checking/greasing of
feed chain gear
DANGER!
Maintenance works must only be carried
out when the joint cutter has been shut
down.
The feed chain gear is part of the feed drive. The feed
chain is mounted between the feed gear drive (chain
wheel on secondary shaft) and the drive wheels (chain
wheel on driving axle) (g. 6.17 and 6.18). Check and
grease the feed chain according to the maintenance
table 6.5.
Check and grease the CF-2116 D’s feed chain as fol-
lows:
1. Remove the water tank and dismount the water tank
console from the CF-2116 D as described in section
6.6.8 (g. 6.17 and 6.15).
CF-2116 D rear side Fig. 6.17
feed chain gear water tank console
chain wheel with feed chain
Joint cutter’s rear side, view on driving axle Fig. 6.18
