Maintenance and care
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
Joint cutter’s rear side, view on chain wheel of driving axle with
feed chain Fig. 6.19
2. If necessary, clean the feed chain gear by removing
adhering dust and old grease from the lubricating
lm. (gs. 6.16 and 6.19).
3. Check the chain links (master link) and the chain
wheels of the feed chain gear on even wear (clear-
ance), mobility, quantity and completeness of teeth
(6.16 and 6.19).
4. Grease the feed chain gear by applying a thin lm of
multi-purpose grease with a brush on the chain.
Excessive greasing will increase wear due to
adhering dust and slurry.
5. Mount the water tank console with the four screws
and nuts (gs. 6.15 and 6.17) and re-tighten all loos-
ened screws.
6. Place the water tank back on the CF-2116 D water
tank console.
6.6.10 Tensioning/changing the feed chain
DANGER!
Maintenance works must only be carried
out when the joint cutter has been shut
down.
For tensioning/changing the CF-2116 D’s feed chain
proceed as follows:
1. Remove the water tank and dismount the water tank
console from the CF-2116 D as described in section
6.6.8 (g. 6.17 and 6.15).
2. Loosen the two nuts of the chain tensioning wheel
(right and left of the gear housing, gs. 6.17 and
6.20).
DANGER!
Danger of squeezing! Pay attention to
your hands and ngers when changing
the chain!
3. For tensioning the feed chain press the chain clamp-
ing wheel forward or pull it backward for releasing
(changing) the feed chain.
Feed gear housing, view on the left and right nut of chain
clamping wheel Fig. 6.20
4. For changing the chain open the master link or cut
a worn chain by means of a saw (angle grinder).
Observe not to damage the chain wheels.
5. Mount the water tank console with the four screws
and nuts (gs. 6.15 and 6.17) and re-tighten all loos-
ened screws.
6. Place the water tank back on the CF-2116 D water
tank console.
6.6.11 Adjusting Bowden cable
of feed lever
The Bowden cable transmits the feed direction and
speed from the feed lever to the hydrostatic feed gear
(gs. 4.8, 4.11 and 6.21).
The Bowden cable of the feed lever has to be adjusted
when the joint cutter is travelling, although the feed
lever is in its neutral position (center) (refer to section
4.3.3).
The Bowden cable of the feed lever is accessible at the
fore of the superstructure box (gs. 6.21 and 6.22).
