ENGLISH
51
Maintenance and care
• CEDIMA
®
• Technical Documentation • All rights reserved as per ISO 16016 • Subject to modications due to progressive development •
Maintain and change the CF-2116 D’s battery as
follows:
1. Remove the water tank and dismount the water tank
console as described in section 6.6.8 (gs. 6.14 and
6.15).
2. Disconnect the leads to the battery poles.
Disconnect the (–) negative lead rst.
ATTENTION!
Never disconnect the battery while the
joint cutter’s motor is still running.
holding angle rear pointer
CF-2116 D, rear side motor starter battery Fig. 6.27
3. Loosen and remove the xing screw from the rear
and front battery holding angle (g. 6.27 and 6.28).
4. Pull the battery carefully from its holding sheet.
If necessary, dismount the rear pointer (g.
6.27).
5. Clean the battery, especially the poles (+/-).
6. Check the acid level and, if necessary, ll distilled
water up to the mark (g. 6.29). For the required acid
density refer to the battery documentation.
CF-2116 D, motor starter battery Fig. 6.28
Battery
Water
pump
holding angle
7. Close the locking caps (g. 6.29).
8. Put the battery back on it holding sheet and secure it
by means of the holding angle (g. 6.27 and 6.28).
locking cap
maximum acic
level
minimum acid
level
motor starter battery Fig. 6.29
9. Re-connect the leads to the battery poles.
Connect the (+) positive lead rst!
10. Check the tight position of the battery and the leads
and apply acid-free grease on the poles.
11. Mount the water tank console with the four screws
and nuts (gs. 6.14 and 6.16) and re-tighten all loos-
ened screws.
12. Put the water tank back on its console.
