MAGNUM SS24000 SPECIFICATIONS
*Sizing the System to the Room
There are several factors such as glass, stone, and concrete which will change the required amount of BTUs needed to properly
cool your wine room. We strongly recommend utilizing the cellar wizard on the CellarCool website in order to ensure you are
selecting the proper cooling system for your application. Under-sizing your cooling system can lead to premature failure and/or
prevent the system from reaching the desired set temperature.
Model
SS24000
(Fan Coil Unit)
H.E. Condenser
(Air-Cooled Condensing Unit)
Cellar Size Approx. 7500 cu. ft. when cellar is fully insulated and sealed with a proper vapor barrier.*
BTU/h w/65°F air entering
condenser coil
22893/26933
H.E. Condenser (Air-Cooled Condensing Unit)
BTU/h w/75°F air entering
condenser coil
21977/25856
BTU/h w/85°F air entering
condenser coil
21519 /25317
Dimensions 29.5”L x 30.9”W x 19.8”H 35.25”L x 12”W x 33.7”H
Refrigerant R-134a
Condensing Unit HP 3 HP
Voltage Rating 120V (15-amp dedicated circuit required) 220V (15-amp dedicated circuit required)
Weight 96 58
Amps 9.2 Running Amps LRA 46.6, RLA 11.39, FLA 13
Line Set Liquid line 3/8” OD; Suction line 5/8” OD (less than 50 ft.), 3/4” (greater than 50 ft.)
Drain Line ¾” ID CPVC
Installation
Evaporator unit is installed in the cellar. Condensing unit can be installed up to 100 line feet from the
evaporator unit.
Thermostat
KDT- Advanced digital display (50-ft. cable), liquid-temperature-measuring bottle probe (50-ft.
cable), 24V - Customer supplied.
Temp. Delta Can maintain a 55°F cellar temperature with up to 120°F condenser air intake temperature.
Warranty Two-year limited warranty (parts and labor).
