TRMS AC/DC Low Current Clamp Meter
14
7. BATTERY REPLACEMENT
When the battery voltage drops below proper operation range,
the symbol will appear on the LCD display and the battery
needs to be replaced.
Before changing the battery, switch the main dial to
“OFF ”and disconnect test leads.
Open the battery cover by a screwdriver.
Replace the old batteries with two new 1.5V (AAA Size)
batteries.
Close the battery cover and fasten the screw.
