EAGLE CONTROLLER – INSTALLATION & COMMISSIONING INSTRUCTIONS
13 EN1Z-0970GE51 R0918
147
57.5
215.5
52
55.5
Fig. 20. EAGLE Controller with built-in HMI (with MVC-80-AC1), dimensions (in mm)
147
57.5
215.5
J1 J8
52
Fig. 21. EAGLE Controller with RJ45 socket for CLEAHMI21 External HMI (with MVC-80-AC1), dimensions (in mm)
NOTE: Use of the covers (MVC-80-AC1) obstructs access to the Ethernet and USB 2.0 Host Interfaces and RS232 socket.
