CentraLine EAGLE User Manual

EAGLE CONTROLLER – INSTALLATION & COMMISSIONING INSTRUCTIONS
EN1Z-0970GE51 R0918 4
SYSTEM OVERVIEW
Overview of Models
Table 3. Overview of models
feature description
max. cable
length
order no.
CLEA2014B21 CLEA2014B31 CLEA2014B22 CLEA2014B32 CLEA2026B21 CLEA2026B31 CLEA2000B21 CLEA2000B31
UI
NTC10kΩ / NTC20kΩ / 0…10V / slow BI, 0.4 Hz 400 m 4 4 4 4 8 8 - -
NTC10kΩ / NTC20kΩ / 0…10V fix pull-up / slow BI, 0.4 Hz 400 m - - - - 2 2 - -
BI
open = 24 V / closed 2.0 mA / totalizer 15 Hz 400 m 4 4 4 4 4 4 - -
AO
0..11 V (max. 1 mA) 400 m 2 2 2 2 4 4 - -
BO
Relay N.O. contact; 3 A, 250 VAC, 30 VDC 400 m 3 3 3 3 4 4 - -
Relay N.O. contact (high in-rush) ; 10 A, 250 VAC, 30 VDC 400 m 1 1 1 1 1 1 - -
Relay N.O. contact with one common; 3 A, 250 VAC, 30 VDC 400 m - - - - 3 3 - -
bus
interfaces
RS485-1, isolated, BACnet MS/TP, Panel Bus
(1)
, or Modbus RTU
Master or Slave communication
(2)
1200 m 1 1 1 1 1 1 1 1
RS485-2, non-isolated, BACnet MS/TP, Panel Bus
(1)
, or Modbus
RTU Master or Slave communication
(2)
1200 m 1 1 1 1 1 1 1 1
Ethernet / RJ45
socket
e-mail communication, browser access 100 m - - 1 1 1 1 1 1
BACnet IP communication 100 m - - 1 1 1 1 1 1
USB 2.0 Device Interface (as Network Interface) 3 m 1 1 1 1 1 1 1 1
USB 2.0 Host Interface (max. 500 mA) 3 m 1 1 1 1 1 1 1 1
RS232 M-Bus communication via PW3 / PW20 / PW60 converters
(3)
1000 m 1 1 1 1 1 1 1 1
user
interface
HMI with graphic LCD -- X - X - X - X -
Fast Access buttons -- 6 - 6 - 6 - 6 -
push and turn button -- 1 - 1 - 1 - 1 -
LEDs
power LED (green) -- 1 1 1 1 1 1 1 1
status LED (red, controllable by firmware) -- 1 1 1 1 1 1 1 1
applications-specific LED L1 (yellow) -- 1 1 1 1 1 1 1 1
LED L2 (reserved) -- 1 1 1 1 1 1 1 1
bus status LEDs (for isolated RS485-1 interface) -- 2 2 2 2 2 2 2 2
Socket for
CLEAHMI21
RJ45 socket for connection of CLEAHMI21 External HMI 5 m -- X -- X -- X -- X
(1)
See also section "Restriction Applying to CLEA2014B21 and CLEA2014B31" on pg. 8.
(2)
Depending upon baud rate. For max. cable lengths, see section "RS485 Standard" on pg. 9. In the case of the Panel Bus, see also section
"Panel Bus Considerations" on pg. 23. In the case of the BACnet MS/TP Bus, see also section "BACnet MS/TP Bus Considerations" on pg. 28.
In the case of the Modbus, see also section "Modbus Considerations" on pg. 31.
(3)
Depending upon baud rate. See also section "M-Bus Considerations" on pg. 33.
