EAGLE CONTROLLER – INSTALLATION & COMMISSIONING INSTRUCTIONS
3 EN1Z-0970GE51 R0918
SPECIFICATIONS OF CONTROLLER
Table 2. EAGLE specifications
Power supply
19 … 29 VAC, 50/60 Hz or
20 … 30 VDC
Power consumption
typically dc: 5 W; max. 6 W
typically ac: 9 VA; max. 11 VA
Current consumption
typically dc: 210 mA; max. 240 mA
typically ac: 370 mA; max. 410 mA
Ambient temperature
0 … 40 °C (wall-mounting)
0 … 50 °C (cabinet/door mounting)
Storage temperature
-20 … +70 °C
Humidity
5 … 95% r.h. non-condensing
Dimensions
See Fig. 18 and Fig. 20.
Degree of protection
IP20 (mounted on walls, with two accessory MVC-80-AC1 covers)
IP30 (mounted in cabinet doors, with accessory MVC-80-AC2)
Fire class
V0
Weight
0.6 kg (excl. packaging)
