CENTURION SYSTEMS D3 - Page 11

PROVISION FOR CABLES
- Ensure cables are fitted through base plate before concreting
in place.
- Remove knock-outs from gearbox to allow for cable entry.
- Route cables in front of battery (D3/D5 motors) as shown above.
- Seal cable entry holes with silicone sealer.
9
47
46 43
47
350 mm
30 mm
46
43
