SETTING GATE LIMITS
22
- Rotate manual release thumbwheel fully clockwise, or until clutch is
fully dis-engaged and gate can be moved by hand.
D3/D5 ONLY
- Slide gate approximately half way open. See above (FIG. 1).
- Re-engage gearbox.
A5 ONLY
- Slide gate to fully closed position (FIG. 2).
- Leave gearbox dis-engaged.
- Skip to page 25-27 and follow START MANUAL GATE LIMITS ROUTINE.
73
1/2 1/2
Fig.2
Fig.1
37
73
37
To Next Page
