CENTURION SYSTEMS D3 - Lightning Protection

RECOMMENDED LIGHTNING PROTECTION
18
- For optimum lightning protection ensure earth cable from charger/PSU unit
is adequately earthed.
- Use ring lug to bond to baseplate mounting stud.
- For additional protection bond baseplate to earth spike .
- In event of damage to charger/PSU unit disconnect quick release link
and push-on connector on controller.
L
N
E
220V AC OUTPUT
220V AC
INPUT
TO CP80/CP81
PCB "DC IN”
LNE
