page 11www.CentSys.com
SECTION 3SPECIFICATIONS
3.2. Technical Specications - VANTAGE Operator
VANTAGE 400 VANTAGE 500
Input voltage 90V - 240V AC ± 10%, 50/60Hz
Motor voltage 12V DC
Motor power supply Battery-driven (standard capacity - 7Ah)
1
Battery charger
2
1.8A @ 13.8V
Current consumption (Mains) 170mA
Current consumption (motor at rated load) 15A - maximum
Operator push force - maximum 250kgf
Operator stroke 400mm 500mm
Piston extension/retraction speed 28mm/sec (variable)
Typical gate opening time
3
14.3 sec 17.8 sec
Manual override Key release
4
Maximum number of operations per day 250
Duty cycle - Mains present
5 6
50%
Operations in standby with 7Ah battery
7
Half day 70
Full day 58
Collision Sensing Electronic
Operating temperature range -15°C to +50°C
Mass of unit packed (excluding battery)
Single kit
8
8.5kg 9kg
Double kit
9
14kg 15kg
1. Can increase battery capacity for longer standby times
2. Can operate o a solar supply, consult your reseller for assistance
3. Assumes a full stroke of operator is used
4. Each operator comes with a unique set of keys
5. Based on 25°C ambient temperature and unit not in direct sunlight
6. Based on an operator push force of less than 50% of rated
7. Based on double kit excluding Infrared Safety Beams
8. Single kit contains one operator and Wall Box
9. Double kit contains two operators and one Wall Box
TABLE 1
