SECTION 3 SPECIFICATIONS
Wind speeds for which operator will still operate the gate.
(VANTAGE 400 or VANTAGE 500 operators)
For a 25% covered gate: (Palisades, etc.) x 1.8 metre high
Value of
A or B
dimension
once
installed
1
Individual gate leaf lengths:
Up to
1.5m
Up to
2m
Up to
2.5m
Up to
3m
2
Up to
3.5m
2
Up to
4m
2
100mm 94km/h 66km/h 48km/h 44km/h 41km/h 37km/h
140mm 119km/h 85km/h 65km/h 57km/h 51km/h 46km/h
180mm 138km/h 101km/h 78km/h 67km/h 60km/h 53km/h
220mm 156km/h 114km/h 89km/h 76km/h 67km/h 60km/h
260mm 171km/h 126km/h 99km/h 84km/h 74km/h 65km/h
300mm 186km/h 137km/h 108km/h 91km/h 80km/h 71km/h
340mm 199km/h 147km/h 116km/h 98km/h 86km/h 76km/h
Wind speeds for which operator will still operate the gate.
(VANTAGE 400 or VANTAGE 500 operators)
For a 100% covered gate: (Fully-clad gates, etc.) x 1.8 metre high
Value of
A or B
dimension
once
installed
1
Individual gate leaf lengths:
Up to
1.5m
Up to
2m
Up to
2.5m
Up to
3m
2
Up to
3.5m
2
Up to
4m
2
100mm 47km/h 33km/h 24km/h 22km/h 47km/h 19km/h
140mm 59km/h 43km/h 32km/h 28km/h 59km/h 23km/h
180mm 69km/h 50km/h 39km/h 34km/h 69km/h 27km/h
220mm 78km/h 57km/h 44km/h 38km/h 78km/h 30km/h
260mm 86km/h 63km/h 49km/h 42km/h 86km/h 33km/h
300mm 93km/h 63km/h 54km/h 46km/h 93km/h 35km/h
340mm 100km/h 74km/h 58km/h 49km/h 100km/h 38km/h
TABLE 6
TABLE 7
1. See Section 9/10 for installation details
2. An electric lock must be tted
1. See Section 9/10 for installation details
2. An electric lock must be tted
3.7. Allowable Wind Load
