4. Product Identication
SECTION 4PRODUCT IDENTIFICATION
FIGURE 3. KIT IDENTIFICATION
5
6
1
2
3
4
7
1. Keys are specic to each operator - key number must be recorded
1
2
8
9
10
11
12
1. Gate Bracket pin
2. 14mm snap ring
3. VANTAGE gate operator
(complete assembly)
4. Wall Bracket
5. Wall Bracket mounting plate
6. Mechanical Installation Manual
7. Gate operator keys
1
8. Stainless steel cap screw M5 x 25
9. Origin clamp
10. M5 barrel nut
11. Gate Bracket
12. Gate Warning Decal
