Centurion Vantage - Allowable Gate Mass Limits

page 13www.CentSys.com
SECTION 3SPECIFICATIONS
3.6. Allowable Gate Mass
Ensure that the gate leaf meets Wind Load Specications
Gate
swing
angle
Up to
1.5m
Up to
2m
Up to
2.5m
Up to
3m
1
Up to
3.5m
1
Up to
4m
1
90° 500kg 500kg 500kg 360kg 260kg 200kg
100° 500kg 500kg 388kg 160kg 190kg 150kg
110° 500kg 306kg 198kg 130kg
120° 180kg 100kg 65kg Not recommended
TABLE 4
1. An electric lock must be tted to secure gate in closed position
Gate
swing
angle
Up to
1.5m
Up to
2m
Up to
2.5m
Up to
3m
1
Up to
3.5m
1
Up to
4m
1
90° 750kg 750kg 750kg 550kg 410kg 310kg
100° 750kg 750kg 600kg 420kg 310kg 230kg
110° 750kg 500kg 320kg 220kg
120° 310kg 170kg 110kg Not recommended
Maximum allowable gate mass for the VANTAGE 500 operator
TABLE 5
1. An electric lock must be tted to secure gate in closed position
Maximum allowable gate mass for the VANTAGE 400 operator
