Centurion Vantage - Fast Track Mechanical Setup

page 4 www.CentSys.com
STEP
1
These quick steps are for the experienced installer who needs a checklist to get a
standard installation up and running in the minimum of time.
Detailed installation features and functions are referred to later in this manual.
Gather Required Tools and Equipment
STEP
2
STEP
3
Heed Necessary Site Considerations
Check Cabling Requirements
STEP
4
Determine Gate Swing Angle
STEP
5
STEP
6
STEP
7
STEP
8
STEP
9
Conrm that gate leaf meets allowable wind loading specications
Determine Installation Type
• Inward Opening Installation
• Outward Opening Installation
Mount the Gate and Wall Bracket(s)
Install Operator and Link to Gate
Mount Controller Enclosure
FAST TRACK Mechanical Setup
MECHANICAL SETUP
